Selling: |
Demo machine with coating unit |
|||
|
|
||||
|
|
||||
| ID | 3000 | |||
| Categories | Press | Sheet-Fed Offset Presses | | |||
|
|
||||
| Short description | Demo machine with coating unit | |||
| Price (in €) | on request | |||
|
|
||||
| Manufacturer | ||||
| Model | Genius 52UV (2011) | |||
| Year of manufacture | 2011 | |||
| Warranty until | --- | |||
|
|
||||
| Long description | Genius 52 UV demo maschine with coating unit from a waterless printing centre The machine has been used for test and demo purposes only. In a technical and optical excellent condition. Year of manufacture: 2011 Milage: 150.000 Sheets List price Manufacturer: 650.000 Euro Includes additional items / equipment: • Die cutting device for plate punching and bending • Control planel / light table with D65 lighting • Ducting and exhaust fans • Platform construction (1.3 x 2.4 m / 51.18 x 94.5“) made of studded steel plates with a tubular frame sub construction to cowl the ducting and exhaust fans – including ca. 10 meters (393.7â€) galvanised straight tubes. • Starters kit General Printing system: waterless offset printing Printing units: 5 Inks: UV curing inks Print substrates: from 0.1 to 0.8 mm (0.004 to 0.03“), (depending on substrate) PVC, ABS, PS, PE, PET, PC, carton and paper Coating unit: Squeeze coater with downstream UV dryer Performance: max. 8.000 sheets/hour (depending on print substrate) Stack height Sheet feeding: 600 mm (23.62“) max. Sheet delivery: 400 mm (15.75“) max. Formats Max. sheet format: 360 x 520 mm (14.2 x 20.47“) Min. sheet format: 210 x 297 mm (8.27 x 11.69“) Max. printing format: 350 x 500 mm (13.78 x 19.69“) Gripper edge: 10 mm (0.39“) Printing plates: waterless, analog or digital Format / thickness: 404 x 540 x 0.3 mm (15.91 x 21.26 x 0.0118“) Plate change: semi automatic, register true, complete plate change in less than 5 minutes Length x Width x Height: 4,850 x 5,400 x 1,910 mm (190.94 x 153.54 x 75.2“) Total weight: 7.25 tons (approx. 16.000 lbs) Air consumption: 1500 l/min (7 bar / 101.5 psi) Power connection Connected load: 3 x 400 V / 230 V (± 10 %) TN S net, 50 Hz Electric power: 38 kVA Amperage: 55 A Backup fuse: 3 x 100 A Offer price: 450.000 Euro netto Delivery time: Immediately available Delivery conditions: Ex works Highlights: • Printing times can be planned for available printing plate sets • Job changeover in no more than 7 minutes • Around ten sheets of run up waste • 1:1 ink transmission by cylinders of identical diameter results in ghosting free prints • Consistently high printing quality from the first to the last print with the anilox short inking unit. Inking is held constant by temperature control over the entire sheet width • Excellent register stability thanks to gripper bite • Urgent printing jobs are possible at short notice • Lower production costs due to smaller footprint of less than 12 m2 • New business fields made possible by high flexibility with extreme substrates More general product information: http://www.kba.com/en/sheetfed offset/sheetfed offset presses/product/genius 52uv/detail/ |
|||
|
|
||||
| Weight | 7.25 tons (approx. 16.000 lbs) | |||
| Dimensions (LxWxH) | 4,850 x 5,400 x 1,910 mm (190.94 x 153.54 x 75.2ï | |||
|
|
||||
| Location | Germany | |||
| Region | ||||
|
|
||||
|
|
||||
|
|
||||
