Buying: |
X Rite i1iO Scantable |
|||
|
|
||||
|
|
||||
| ID | 1375 | |||
| Categories | Measuring Devices | | |||
|
|
||||
| Short description | X Rite i1iO Scantable | |||
| Price (in €) | on request | |||
|
|
||||
| Manufacturer | ||||
| Model | --- | |||
| Year of manufacture | 0000 | |||
| Warranty until | --- | |||
|
|
||||
| Long description | GretagMacbeth Eye One iO scan table Qualities: Automatic measuring table for all i1Pro measuring instruments allows constant and reliable measuring results avoids manual measuring mistakes if the productiveness increases Measuring speed up to 500 fields per minute (depending on the type used i1Pro) Suitable for substrates up to 10 mm of thickness Automatic holding on of the substrate by electrostatic loading of her Measuring surface For quick scanning measuring special test charts are required, the following parametres keep: Testchartgröße to 32 cm * 23 cm possibly Field size minimally 5 mm * 5 mm Colour distance between two fields ΔE> 10 or 1 mm of gaps between the fields (black or knows) Files to the expression of test charts and their authoritative files are in him to respective software programmes available, also the control of the device permit. In the single measuring mode every current Testchart is measurable (5 mm * 5 mm of fields). technical data: i1Pro (spectral measuring head) Measuring geometry: 45 °/0 ° ring optics (circular lighting) Source of light: gas filled wolfram lamp, light kind A Screen diameter: 4.5 mm Measuring area: 380 nm 730 nm, reflexion from 0 to 200% Spectral resolution: Inside: 3.5 nm, issue: 10 nm Device divergence: middle ΔE94 <= 0.4 (more than 12 tiles BCRA) Repeat exactness: ΔE94 = 0.1 (on white ceramics) Measuring surface/ unterlage:weiss after ISO 12647 / defined base possibly Physical filters: No or UV cut (not changeable) Interface: USB 1.1 |
|||
|
|
||||
| Weight | --- | |||
| Dimensions (LxWxH) | --- | |||
|
|
||||
| Location | Germany | |||
| Region | NRW | |||
|
|
||||
|
|
||||
|
|
||||
| View this article on the vendor's web site. | ||||
